FD300 30 Ton Steel Mill Slab Handling Forklift With Heavy Duty Forged Fork Arms

A steel mill is not a container yard and should not be served by a container truck. The FD300S takes the 30 tonne platform and specifies it for slab, bloom and billet handling: forged fork arms instead of welded tines, a heat shield between the mast and the operator, scale resistant paint on all upward facing surfaces, a fire resistant hydraulic fluid option and an air intake routed above the dust zone. The 4000 mm mast keeps the machine compact inside mill buildings, and the hydraulic system is fitted with an additional 10 micron return filter to cope with the fine scale that defeats standard filtration.

• Forged Fork Arms Solid forged 1800 mm fork arms replace welded tines, delivering the impact tolerance needed when setting down a 30 tonne slab on uneven mill floor.
• Heat Shielding A stainless heat shield on the mast and an insulated cabin floor protect the operator and hydraulic lines from radiant heat near hot slabs.
• Scale Resistant Protection Upward facing surfaces receive a scale resistant coating, and all pivot pins use sealed bushes rated for abrasive dust environments.
• Elevated Air Intake The engine intake draws from above the mill dust band, paired with a two stage filter and a cyclone pre cleaner for extended element life.
• Fine Filtration Hydraulics An additional 10 micron return filter circuit removes the fine scale particles that accelerate pump and valve wear in mill service.
• Slab Handling Front End Optional slab clamps, coil rams and billet grabs can be fitted, each supplied with a matching residual capacity chart.

Integrated steel mills, rolling mills, slab yards and heavy forging plants where 20 to 30 tonne slabs, blooms or billets move between cooling beds, storage rows and furnace charging areas. The same chassis accepts a coil ram for coil duty, so one model can cover multiple product forms inside a single plant.

A slab yard at a mill in Hebei had averaged 640 hours between hydraulic pump failures on general purpose trucks. Three FD300S units with fine filtration, elevated intake and heat shielding reached 2,400 hours on the original pumps. Slab handling cycle time improved by 14 percent, mainly because the forged arms eliminated the tine straightening work that had previously taken trucks out of service.

SLD is a specialised heavy lift forklift manufacturer with a product range from 12 to 45 tonnes and a factory footprint of 86,000 square metres. The plant includes a mast welding line, a 200 tonne vehicle test station and a full paint and assembly hall, supported by 320 production staff and 40 engineers. Around 65 percent of annual output is exported to over 70 countries, and the company maintains CE, ISO 9001 and SGS certifications with annual third party inspection. Service parts are stocked in four regional warehouses.

Eighteen years of building counterbalance trucks shows in the details. Early units in this series went into steel coil yards in 2011, and the driveline, mast section and hydraulic cooling package have been revised nine times based on that field data. Weld procedures follow ISO 3834 practice, each mast is load tested at 125 percent of rated capacity, and every truck completes a 4 hour run in test before shipment. Warranty return rate on the heavy lift range sits below 1.8 percent across the last three production years.

Q: Can the truck handle hot slabs directly?
The specification is rated for radiant heat from slabs at up to 600 degrees Celsius at a three metre distance. Direct contact handling of hotter material requires a dedicated heat resistant attachment and is outside the standard rating.

Q: Are the forged forks replaceable individually?
Yes. Each forged arm is individually mounted on the carriage, so a single damaged arm can be replaced without changing the pair.

Q: What hydraulic fluid is recommended?
Standard ISO VG 68 mineral oil is supplied. A fire resistant fluid option is available for areas where molten material is present.

Q: How does scale affect maintenance intervals?
Hydraulic filters are changed at 250 hours instead of 500 in mill duty. Sealed bushings at pivot points are greased at 100 hours rather than 250.

Q: Is a coil ram available for this model?
Yes. A 30 tonne rated coil ram with a 1600 mm spread can be fitted, with residual capacity derated to 24,000 kg.

Shipping follows flat rack or break bulk depending on destination port, with the mast folded, forks removed and every hydraulic port sealed against moisture. Delivery is 30 working days from confirmed order. T/T and L/C payment terms apply, minimum order one unit. A 12 month or 2,000 hour warranty covers the frame, mast, transmission and hydraulic system, and the export team provides loading supervision, fumigation certificates and a two year recommended spare parts schedule with the shipment.
