40 Ton Shipyard Heavy Duty Forklift Truck Handling Large Steel Blocks Safely

40 Ton Shipyard Heavy Duty Forklift Truck Handling Large Steel Blocks Safely
40 Ton Shipyard Heavy Duty Forklift Truck Handling Large Steel Blocks Safely 40 Ton Shipyard Heavy Duty Forklift Truck Handling Large Steel Blocks Safely 40 Ton Shipyard Heavy Duty Forklift Truck Handling Large Steel Blocks Safely

Large Image :  40 Ton Shipyard Heavy Duty Forklift Truck Handling Large Steel Blocks Safely

Product Details:
Place of Origin: China
Brand Name: SLD
Certification: ISO, CE
Model Number: FD400
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: USD196,800.00~USD215,600.00 / Unit
Packaging Details: Flat rack container
Delivery Time: 30 working days
Payment Terms: T/T, L/C
Supply Ability: 30 units per month
Contact Now
Detailed Product Description
Rated Capacity: 40,000 Kg Lift Height: 4000 Mm
Load Center: 1250 Mm Engine Model: WD10G240E21 (WEICHAI)
Transmission: ZL60 Front Tire: 4 X 14.00-24-32PR
Color: Orange Red, Yellow, Customized OEM: Customized
Highlight:

40 ton shipyard forklift

,

heavy duty forklift truck

,

steel block forklift

40 Ton Shipyard Heavy Duty Forklift Truck

The FD400 heavy lift forklift truck is engineered for the most demanding lifting duties in shipyard steel block handling, hull section transport, dry dock logistics, and heavy fabrication movement. Rated at 40,000 kg at a 1250 mm load center, this industrial powerhouse combines Weichai turbocharged diesel power with reinforced construction for stable, predictable performance shift after shift.

Key Features
  • Reliable Weichai Turbocharged Power: WD10 series turbocharged diesel engine delivers strong torque and low fuel consumption
  • Heavy Duty Box-Type Frame: Reinforced frame verified through 3D finite element analysis with non-destructive weld testing
  • Reinforced Hub Reduction Axle: High-strength axle case and hub reduction design for excellent stability under 40,000 kg loads
  • Full-Hydraulic Steering: Transverse oil cylinder steering bridge provides flexible, reliable steering even under maximum load
  • Four Caliper Disc Brakes: Thickened discs with rear air tank for stable braking and fast heat dissipation
  • Pilot Valve Control: Enhances working efficiency and reduces driver labor intensity
  • Independent Cooling: Separate transmission oil and hydraulic oil cooling maintains system stability
  • Comfortable Cab: Air-conditioned cab with rupture membrane, heat/sound insulation, sunroof, and damping seat
Technical Specifications
Parameter Specification Unit
Model FD400 —
Power Type Diesel —
Rated Capacity 40,000 kg
Load Center 1250 mm
Lift Height 4000 mm
Fork Size 2500x320x130 mm
Overall Width 3400 mm
Wheelbase 5000 mm
Service Weight 50,000 kg
Max Traction (Load) 260 kN
Travel Speed (Unload/Load) 26/22 km/h
Lifting Speed (Unload/Load) 235/165 mm/s
Engine Model WD10G240E21 (WEICHAI) —
Rated Output 210 kW
Transmission ZL60 —
Front Tire 4 x 14.00-24-32PR —
Note: The above data are subject to change without prior notice. Custom masts, forks, attachments and lifting heights are available for special heavy lift projects.
Applications

The FD400 is specified for shipyard steel block handling, hull section transport, dry dock logistics, and heavy fabrication movement. Its 40,000 kg capacity, full-hydraulic steering and heavy duty chassis make it equally effective in continuous terminal cycles and in yard, mill or fabrication shop duty.

Frequently Asked Questions
Can it move hull sections?
Yes, with appropriate forks, spreader or customized carriages the machine transports large fabricated steel blocks and hull sections.
What is the rated capacity?
Rated capacity is 40,000 kg at a 1250 mm load center.
How is stability ensured?
A long wheelbase, wide tread, box-type frame and hub reduction axle deliver high stability under extreme load.
Does it suit shipyard surfaces?
Yes, high ground clearance and heavy duty tyres handle plate, roadway and dock surfaces.
What after sales support is provided?
Long term spare parts supply, remote diagnostics and engineer visits are available for shipyard fleets.
Quality Assurance & Support

Every FD400 is prepared for ocean freight with corrosion protection and secured fixings. Documentation includes operation manual, spare parts catalogue and warranty statement. The forklift carries a 12-month or 2000-hour warranty on major components, supported by overseas spare parts channels and remote technical help.
