35 Tons Powerful High Capacity Forklift With Fork Attachment Superior Performance

Certification
China Xiamen Sealand Development Co., Ltd. certification
China Xiamen Sealand Development Co., Ltd. certification
Customer Reviews
Ordered SLD 12 tons and 16 tons forklifts , good quality, perfect service, looking forward to more cooperation.

—— Mohammad Asharf

SLD 30 tons forklift, It was my good choice, will buy more forklifts.

—— Ricky So

I'm Online Chat Now

35 Tons Powerful High Capacity Forklift With Fork Attachment Superior Performance

35 Tons Powerful High Capacity Forklift With Fork Attachment Superior Performance
35 Tons Powerful High Capacity Forklift With Fork Attachment Superior Performance 35 Tons Powerful High Capacity Forklift With Fork Attachment Superior Performance

Large Image :  35 Tons Powerful High Capacity Forklift With Fork Attachment Superior Performance

Product Details:
Place of Origin: China
Brand Name: SLD
Certification: ISO, CE
Model Number: FD350
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: USD54,980.00~USD63217.00 unit
Packaging Details: 40HQ containers
Delivery Time: 30 working days
Payment Terms: L/C, T/T
Supply Ability: 100 units per month
Detailed Product Description
Rated Load: 35000kgs Load Center: 1250 Mm
Mast Lifting Height: 4000mm Fork Length: 2400
Engine: Cummins Transmission: Hydraulic
Warranty: 1-2 Years
Highlight:

35 Tons High Capacity Forklift

,

Hydraulic Transmission Heavy Lift Forklift

,

Turbocharging Engine Heavy Lift Forklift



35 Tons Powerful High Capacity Forklift With Fork Attachment Superior Performance

Main features:



Engine:

Adopt Cummins or Weichai turbocharging engine, 6 cylinder, powerful, energy conservation,

environmental protection, satisfies the requirement of high efficiency operation.



Transmission & Torque converter:

Use Hangchi (ZF technology) hydraulic power shift transmission, big traction in combined operating condition, the transmission system more reliable. Adopt double turbine hydraulic torque converter, stepless speed change, single lever control for the speed changing, easier for operation. Variable speed control valve matched with neutral starter, the machine start more secure.

Driving axle :

Use heavy load driving axle (Kessler technology), four sets heavy caliper disc brake, thicken brake disc, the rear air tank, 18 times braking pressure strength ratio, heat dissipation faster, with enlarged axle housing, hub and bearings. Spiral bevel gear and wheel rim planetary deceleration increase torsion, make sure strong heavy load capacity and long service life.



Steering axle:

Adopts transverse hydraulic cylinder steering mechanism, hydraulic load sensing steering system. The structure of the steering axle is compact, the transmission angle can reach 70.5°, which is better to reduce the steering resistance and reduce the wearing of the tyre, increase the smooth and flexible when travelling.



Hydraulic system:

Adopt double pump confluence working hydraulic system, greatly reduce fuel consumption, energy consumption. Hydraulic system equipped with oil radiator and back pressure protection device, ensure the machine heat balance.
Using speed limit valve and pressure selector valve, reduce the hydraulic system impact, can lower the mast to the ground when engine flame out.



Electric system:

Using domestic high quality electrical components, maintenance-free battery, the wire resistance of flame retardant materials, reliable and durable.



Frame & Mast structure system:
Optimize structural design, combine finite element mechanical analysis to verify the stiffness and strength calculation, fatigue life prediction, ensure product safety in use of forklifts.

Adopt long wheelbase, box type double beam frame, can provide good rigidity and strength, to ensure the high reliability of forklift truck chassis.

Inner and outer mast adopts roller operate, fall block force-saving structure, high reliability.

Hydraulic fork positioner, easy to adjust. Cascade high strength fork, more wear-resisting, can multiply service life .

Tire:

Adopt port specific tires with deep pattern, strong load-bearing capacity, good durability and quality



Cabin:

Closed cabin with A/C. Luxury wide view cabin, along with the skylight, low noise, good sealing, adjustable steering wheel, comfortable Aero seat, Aero joystick control. with fan, radios, reversing display etc.



Parameters:

General Model   FD350
Rated Load Kg 35000
Load Center mm 1250
Wheelbase mm 5000
Service Weight kg 42000
Dimensions Mast tilt angle (front/rear) Deg 6°/12°
Mast lowered height mm 4050
Lifting height mm 4000
Max. extended height mm 6030
Overhead guard (cab) height mm 3790
Overall length (with forks) mm 9850
Length to face of fork (without fork) mm 7450
Overall width mm 3360
Fork carriage width mm 3130
Fork size L*W*H mm 2400x300x120
Mast min ground (with load) mm 350
Wheelbase center min ground (with load) mm 400
Min.turning radius mm 7650
Chassis Front tire   16.00-25-32PR
Rear tire   16.00-25-32PR
Tires Qty, front/rear   4/2
Front wheel tread mm 2270
Rear wheel tread mm 2230
Performance Max.. lifting speed (with load/without load) mm/s 260/280
Travel speed (with load/without load) km/h 25/28
Traction force KN 200
Max.. gradeability(with load/without load) % 20/20
Engine Manufacturer   WeiChai Engine
Model   WP10G240E341
Rated power / Rated speed kw/rpm 178/2200
Cylinder Number   6
Transmission Transmission gears(Front/rear)   2/1

Note: the above data are subject to change without prior notice.
