Product Details:
Payment & Shipping Terms:
|
Engine: | Weichai, CUMMINS | Power: | 194KW |
---|---|---|---|
Transmission: | Electronic Control Hydraulic Powershift | Rated Load: | 30000kgs |
Load Center: | 1200mm | Mast Lifting Height: | 4000mm |
Fork Size: | 2400x300x120mm | Color: | Yellow, Customized |
New Or Used: | New | Performance: | Quality Product |
Highlight: | 32 Tons Container Forklift,Cummins Engine Container Forklift,Kessler Drive Axle Heavy Lift Forklift |
30 Ton 32 Tons Container Forklift With Cummins Engine Kessler Drive Axle Use In Shipping Company
Main Features of FD300 FD320 heavy forklift truck:
Engine: Cummins engine, strong power, energy conservation and environmental protection.
Transmission & torque converter: ZF Hydraulic transmission special for heavy-duty forklift, imported technology, reliable performance, convenient maintenance, smooth transmission and convenient operation.
Driven axle: Kessler driven axle, hub reduction, high strength axle case, large load capacity, excellent stability and reliability.
Steering system: Adopt heavy-load steering axle, transverse oil cylinder type steering bridge, full-hydraulic steering, flexible and light, reliable.
Control system: Pilot valve control device to make the work efficiency and reduce drivers’ labor intensity.
Hydraulic system: Adopt import hydraulic pumps and control valves, double pump confluence, small system flow, low power consumption, reliable performance, excellent operating performance
Cooling system: Adopt independent transmission oil and hydraulic oil cooling, increasing system stability.
Frame structure: Exquisite workmanship &firm box-type frame, improve the transverse, longitudinal stability of vehicles. The vehicle get through the 3D finite element analysis, superior structure, reliable quality, the main welding parts through the nondestructive testing, effective coordination with the reinforced structure,bridge,box.
Tyre: Sino-us joint brand, resistant to wear and sting, high strength tyres, bear heavy loaded - safe and reliable.
Mast: Wide view Internal-external mast, special all-round roller bearings, strengthen performance.
Overhead guard: with ROPS protection device, safety and reliability.
Parameters: | Vehicle configuration | FD300 | ||
Performance | Rated load | 30000 | ||
Load center | 1250 | |||
Mast tilt angle (front/rear) | º | 6/12 | ||
Overall dimensions | Length | mm | 9640 | |
Width | mm | 3200 | ||
Height | mm | 4010 | ||
Mast lifting height | mm | 3500 | ||
Fork size (L*W*H) | mm | 2400X300X120 | ||
Min. turning radius | mm | 6600 | ||
Max. travel speed (with load) | Km/h | 24 | ||
Lifting speed (with load) | mm/s | 280 | ||
Gradeability (with load) | % | 20 | ||
Weight | Kg | 38000 | ||
Tyre | Front | 4X24.00-32PR | ||
Rear | 2X24.00-32PR | |||
Wheel tread | Front | mm | 2330 | |
Rear | mm | 2140 | ||
Wheelbase | mm | 4800 | ||
Min. ground clearance | mm | 350 | ||
Engine | Model | WD10G240 | ||
Rated power | KW | 178 | ||
r.p.m | 2200 |
Note: the above data are subject to change without prior notice.
