Product Details:
Payment & Shipping Terms:
|
Rated Load: | 10000kgs | Lift Height: | 3000mm |
---|---|---|---|
Overall Dimension(without Fork): | 4280x2170x2830mm | Power Type: | Diesel |
Service Weight: | 13000mm | Load Center: | 600mm |
Wheelbase: | 2800mm | Fork Size: | 1520x175x85mm |
Engine: | ISUZU | Transmission: | Hydraulic |
High Light: | Multi Stage 10 Ton Forklift,Diesel Powered 10 ton Forklift,1520x175x85MM Diesel Forklift Truck |
Characteristics & Advantages
Available with a range of high performance industrial engine, imported gear-box, multi-stage torque converter, big converter ratio, wide range of auto-adjust speed. stable and smooth shift.
The steering with load sensor and adjustable steering device make the operation easily.
Load sensor hydraulic system, dual pumps supply, dynamic load sensor priority, reduce power consumption., lower the hydraulic oil temperature.
Tilted structure is easy for maintenance;
Small column and steering wheels increase the operator space.
Feature
High quality
-- Reasonable layout of hose and hard pipe, reduce oil pressure loss;
-- The mature and reliable engine provides plenty of power;
-- The super large capacity aluminum tube belt radiator and optimized heat dissipation channel further improve the heat dissipation capacity of the vehicle;
-- The enhanced transmission system has stronger shock resistance and bump resistance.
High security
-- Wide vision mast provides a good front view, accurate disassembly of goods. The grille roof guard provides good upper visual field for drivers;
-- Standardized LED lamp, high brightness, long life, energy saving and environmental protection.
High comfort
-- Standard small diameter steering wheel, light control, reduce driver fatigue;
-- The combined color instrument has strong human- -machine interaction and timely and accurately feedback the running state of vehicles;
-- Spacious control space, comfortable seats, enjoy the pleasure of riding.
Rich options
-- high exhaust device, air prefilter, fireproof cap, solid tire, two stage free lift mast, three stage free lift mast, widening fork frame, fork sleeve, side shifter, paper roll clamp, bale clamp, carton clamp, block clamp, rotators, drum clamp, push-pull, etc.
Product Info
l | ||||
Model | FD100 | FD120 | ||
Power Type | Diesel | Diesel | ||
Load Capacity | kg | 10000 | 12000 | |
Load centre | mm | 600 | 600 | |
Tyre | ||||
Tyre | Pneumatic Tyre | Pneumatic Tyre | ||
Front Tyre | 9.00-20-14PR | 11.00-20-16PR | ||
Rear Tyre | 9.00-20-14PR | 9.00-20 | ||
Overall Dimension | ||||
Lift Height | mm | 3000 | 3000 | |
Fork Size | L×W×T | mm | 1520×175×85 | 1520×180×100 |
Mast Tilt Angle | F/R | . | 6/12 | 6/12 |
Mast Lowered Height | mm | 2830 | 3080 | |
Mast Extended Height(with backrest) | mm | 4335 | 4500 | |
Length to face of fork(Without fork) | mm | 4280 | 4700 | |
Overall Width | mm | 2170 | 2200 | |
Overhead Guard Height | mm | 2570 | 2590 |
Why choose us?
1.Best quality-Shantui has over 100 years history & One of China biggest forklift factory.
2.Advanced technology
3.Service-SHANTUI service everytime everywhere.
4.Spare parts-all parts of our products that you need can be provide.
5. Certificate: CE ISO9001, SGS COC, CO GHOST...
6.Market: Goods have been sold to over 140 countries and regions.
